Kuma Meshes Part I - The basics. Explaining the basics of how Meshes and Kuma Meshes work. It goes through how to get a cluster ready to start making tests with Kuma by diving into kubernetes concepts and quick installation command installations.

1. How it works, what we can monitor with it and why is it
different
By João Esperancinha (2024/03/31)

2. Who am I?
Overview
Understanding the problems
Project objective
Target audience
Market trends
Cycle diagram
João Esperancinha
● Java
● Kotlin
● Groovy
● Scala
● Software Engineer 10+ years
● JESPROTECH owner for 1 year
● Kong Champion
● Java Professional
● Spring Professional

3. Intro
What is Kuma?

4. Intro - What is Kuma?
Kuma is a platform agnostic
open-source control plane for
service mesh and microservices
management, with support for
Kubernetes, VM, and bare metal
environments.
https://kuma.io/docs/2.6.x/introduction/overview-of-kuma/

5. Chapter I
Getting the services
up and running

6. Chapter I - Summary
Before even beginning exploring Kuma we need a
complete cluster and a functional application system
01 | Our application
02 | Installing all commands
03 | Creating a Cluster
04 | Creating a local docker registry
05 | Going through the code
06 | Making the deploy scripts
07 | Running the Demo application

7. Step 1
Our application
Chapter I
https://github.com/jesperancinha/wild-life-safety-monitor

8. Chapter I - Our Application
Albatross pictureby chrispearson72 Flickr stream CC BY 2.0 DEED / https://nl.wikipedia.org/wiki/Albatrossen#/media/Bestand:Black_Browed_Albatross_gnd.jpg

9. Chapter I - Our Application
Albatross pictureby chrispearson72 Flickr stream CC BY 2.0 DEED / https://nl.wikipedia.org/wiki/Albatrossen#/media/Bestand:Black_Browed_Albatross_gnd.jpg

10. Step 2
Installing all
commands
Chapter I

11. What do we need in general
1
A cluster to get our pods running.
This will be achieved with kind.
(kubernetes in docker)
3
A way to manage and configure our pods.
This will be achieved with kubectl
2
A local registry that we can access inside
our deployment environment.
This will be achieved with kind
4
A command to allow Kuma to install the
environment and inject the sidecars.
This will be achieved with kumactl.
Chapter I - Our Application

12. Step 3
Creating
a Cluster
Chapter I

13. Chapter I - Our Application
kind create cluster --name=wlsm-mesh-zone
kubectl cluster-info --context kind-wlsm-mesh-zone
Creating a Cluster

14. Chapter I - Our Application
helm repo add kuma https://kumahq.github.io/charts
helm repo update
helm upgrade -i kuma kuma/kuma
helm install --create-namespace --namespace kuma-system kuma kuma/kuma
Creating a Cluster - Control Plane GUI

15. Step 4
Creating a
local docker
registry
Chapter I

16. Chapter I - Our Application
./kind-with-registry.sh
Creating a local docker registry

17. Chapter I - Our Application
docker build . --tag localhost:5001/wlsm-listener-service;
docker push localhost:5001/wlsm-listener-service;
Creating a local docker registry

18. Step 5
Going
through
the code
Chapter I

19. Chapter I - Our Application
spring.r2dbc.url=r2dbc:postgresql://wlsm-database-deployment.wlsm-namespace.svc.cluster.local:5432/wlsm
Going through the code
wslm.url.collector=http://wlsm-collector-deployment.wlsm-namespace.svc.cluster.local:8081/api/v1/collector
Listener Service
Collector Service

20. Step 6
Making
the deploy
scripts
Chapter I

21. Chapter I - Our Application
apiVersion: v1
kind: Namespace
metadata:
name: wlsm-namespace
labels:
kuma.io/sidecar-injection: enabled
---
Making the deploy scripts
---
apiVersion: v1
kind: Service
metadata:
name: wlsm-listener-deployment
spec:
selector:
app: wlsm-listener
ports:
- protocol: TCP
appProtocol: http
port: 8080
apiVersion: apps/v1
kind: Deployment
metadata:
name: wlsm-listener
namespace: wlsm-namespace
spec:
replicas: 1
selector:
matchLabels:
app: wlsm-listener
template:
metadata:
labels:
app: wlsm-listener
spec:
containers:
- name: wlsm-listener-service
image: localhost:5001/wlsm-listener-service:latest
imagePullPolicy: Always
ports:
- containerPort: 8080

22. Step 7
Running
the application
Chapter I

23. Chapter I - Our Application
Running the application
kubectl apply -f listener-deployment.yaml --force;

24. Chapter II
Exploring
Kuma features

25. Chapter II - Exploring Kuma features
MeshTrafficPermission
echo "apiVersion: kuma.io/v1alpha1
kind: MeshTrafficPermission
metadata:
namespace: kuma-system
name: mtp
spec:
targetRef:
kind: Mesh
from:
- targetRef:
kind: Mesh
default:
action: Allow" | kubectl apply -f -

26. Chapter II - Exploring Kuma features
Mesh
echo "apiVersion: kuma.io/v1alpha1
kind: Mesh
metadata:
name: default
spec:
mtls:
enabledBackend: ca-1
backends:
- name: ca-1
type: builtin" | kubectl apply -f -

27. Chapter II - Exploring Kuma features
MeshTrafficPermission (Deny)
apiVersion: kuma.io/v1alpha1
kind: MeshTrafficPermission
metadata:
namespace: kuma-system
name: mtp
spec:
targetRef:
kind: Mesh
from:
- targetRef:
kind: Mesh
default:
action: Deny" | kubectl apply -f -

28. Chapter II - Exploring Kuma features
MeshTrafficPermission (Specific)
echo "
apiVersion: kuma.io/v1alpha1
kind: MeshTrafficPermission
metadata:
namespace: kuma-system
name: wlsm-database
spec:
targetRef:
kind: MeshService
name: wlsm-database-deployment_wlsm-namespace_svc_5432
from:
- targetRef:
kind: MeshService
name: wlsm-collector-deployment_wlsm-namespace_svc_8081
default:
action: Allow" | kubectl apply -f -

29. Chapter II - Exploring Kuma features
MeshFaultInjection (Specific)
echo "
apiVersion: kuma.io/v1alpha1
kind: MeshFaultInjection
metadata:
name: default
namespace: kuma-system
labels:
kuma.io/mesh: default # optional, defaults to `default` if it isn't configured
spec:
targetRef:
kind: MeshService
name: wlsm-collector-deployment_wlsm-namespace_svc_8081
from:
- targetRef:
kind: MeshService
name: wlsm-listener-deployment_wlsm-namespace_svc_8080
default:
http:
- abort:
httpStatus: 500
percentage: 50" | kubectl apply -f -

30. ● Source Repository
○ https://github.com/jesperancinha/wild-life-safety-monitor
Use git clone from the command prompt to download the full code base:
> git clone https://github.com/jesperancinha/wild-life-safety-monitor.git
You’ll be prompted for a username and password which should be your github account.
The easy way:
> make b
> make run
The manual way:
> gradle build
> ./gradlew run
Project Location

31. Resources:
● K9s
● https://support.konghq.com/support/s/article/How-to-enable-debug-logging-for-kuma-sidecar-without-
using-port-forward
● https://spacelift.io/blog/kubectl-logs
● https://docs.konghq.com/mesh/latest/policies/meshtrafficpermission/
● https://kuma.io/features/
