HOW TO BUILD A SITE USING
NICK
A NEARLY HEADLESS CMS
Plone Conference 2023, Eibar
-
Rob Gietema @robgietema

WHAT WILL WE COVER?
What is Nick?
Why?
Architecture

Bootstrap a project
Configuration file
i18n
Logging
Profiles
Contenttypes
Behaviors
Initial Content
Permissions, Users,
Groups & Workflows
Vocabularies
Catalog & Search
Events
Controlpanels
Tests
Docs
WHAT WILL WE COVER?

WHAT IS NICK?
Headless CMS
Build with Node.js
RESTfull API compatible with plone.restapi (Volto)

WHY?
Fun to build!
Plone has a great architecture, great way to learn the
internals
Plone has a great Rest API
Started as a proof of concept on Ploneconf 2018 in
Tokyo
Frontend and backend using the same language

ISSUES WITH PLONE
Disclaimer: my opinion
Lots of legacy code
Lot of code to maintain ourself
Deployment

COMPLEX STACK
Python
Zope
Generic Setup (xml)
ZCML
Page templates
REST
Yaml
JSON
cfg
ini
Markdown
Javascript
Webpack
CSS / LESS / SASS
XSLT
Buildout
KSS
Portal Skins
Restricted Python
DTML

LANGUAGES
Javascript
JSON
Markdown

STORAGE
Postgres (Transactional, JSON integration, (text)
indexing)
Knex.js ( )
Objection.js ( )
knexjs.org
vincit.github.io/objection.js/

BLOBS
myproject
└─ var
└─ blobstorage
└─ 1d2362de-8090-472b-a06a-0e4d23705f3c
└─ 2bd8d8f2-6d01-4f39-a799-a521acd17dbf
└─ 5e178390-2cf6-498b-9bb3-424c1aa4dea3
└─ ...

ONLINE DEMO
https://demo.nickcms.org

DOCUMENTATION
https://docs.nickcms.org

CONTRIBUTE
https://github.com/robgietema/nick

CREATE THE DATABASE
CREATE DATABASE myproject;
CREATE USER myproject WITH ENCRYPTED PASSWORD 'myproject';
GRANT ALL PRIVILEGES ON DATABASE myproject TO myproject;

YEOMAN GENERATOR
$ npm install -g yo
$ npm install -g @robgietema/generator-nick
$ yo @robgietema/nick myproject

BOOTSTRAP & START
$ cd myproject
$ yarn bootstrap
$ yarn start

CONFIG
myproject/src/config.js
export const config = {
connection: {
port: 5432,
host: 'localhost',
database: 'myproject',
user: 'myproject',
password: 'myproject',
},
blobsDir: `${__dirname}/var/blobstorage`,
port: 8000,
secret: 'secret',
clientMaxSize: '64mb',
systemUsers: ['admin', 'anonymous'],
systemGroups: ['Owner'],
cors: {

VOLTO CONFIG
import '@plone/volto/config';
import applyAddons from './config-addons.js';
export default function applyConfig(config) {
config.settings.devProxyToApiPath = 'http://localhost:8000';
config.settings.proxyRewriteTarget = new String('');
return applyAddons(config);
}

I18N
myproject
└─ locales
└─ en
└─ LC_MESSAGES
└─ myproject.po
└─ nl
└─ LC_MESSAGES
└─ myproject.po
└─ myproject.po
└─ en.json
└─ nl.json

I18N IN JS
req.i18n('Translate me please!')

I18N IN JSON
{
"id": "talk",
"title:i18n": "Talk",
"description:i18n": "Content type for a talk.",
...
}

LOGGING (LOG4JS)
log.info('My message!')
2022-05-30T22:21:06.317 INFO [my-file.js:12] My message!

SEEDS / PROFILES
myproject
└─ src
└─ profiles
└─ default
└─ types
└─ schedule.js
└─ talk.js
└─ groups.js
└─ permissions.js
└─ ...
$ yarn seed
$ yarn reset

CONTENTTYPES
myproject
└─ src
└─ profiles
└─ default
└─ types
└─ schedule.json
└─ talk.json

SCHEDULE.JSON
{
"id": "Schedule",
"title:i18n": "Schedule",
"description:i18n": "Schedule for a conference.",
"global_allow": true,
"filter_content_types": true,
"allowed_content_types": ["Talk"],
"schema": {
"fieldsets": [
{
"fields": ["year"],
"id": "default",
"title:i18n": "Default"
}
],

TALK.JSON
{
"id": "Talk",
"global_allow": false,
"allowed_content_types": [],
"schema": {
"fieldsets": [
{
"fields": ["title", "description"],
"id": "default",
}
],

BEHAVIORS
myproject
└─ src
└─ profiles
└─ default
└─ behaviors
└─ author.json

AUTHOR.JSON
{
"id": "author",
"title:i18n": "Author Information",
"description:i18n": "Adds firstname, lastname, bio and pictu
"schema": {
"fieldsets": [
{
"fields": ["firstname", "lastname", "bio", "picture"],
"id": "default",
}
],
"properties": {
"firstname": {
"title:i18n": "Firstname",

NESTED BEHAVIORS
{
"id": "author",
"title:i18n": "Author Information",
"description:i18n": "Adds name and bio fields.",
"schema": {
"behaviors": ["name", "bio"]
}
}

BEHAVIORS (CLASS BASED)
myproject
└─ src
└─ behaviors
└─ id_title_from_year
└─ id_title_from_year.js
└─ index.js

DOCUMENT MODEL
/**
* Document Model.
* @module models/document/document
*/
/**
* A model for Document.
* @class Document
* @extends Model
*/
export class Document extends Model {
...
/**

ID_TITLE_FROM_YEAR.JS
/**
* Id and title from year behavior.
* @module behaviors/id_title_from_year/id_title_from_year
*/
import { uniqueId } from '@robgietema/nick/src/helpers/utils/u
/**
* Id and title from year behavior.
* @constant id_title_from_year
*/
export const id_title_from_year = {
/**
* Set id
* @method setId

SRC/BEHAVIORS/INDEX.JS
/**
* Point of contact for behaviors.
* @module behaviors
*/
import { id_title_from_year } from './id_title_from_year/id_ti
const behaviors = {
id_title_from_year,
};
export default behaviors;

CONFIG
import behaviors from './src/behaviors';
connection: {
port: 5432,
host: 'localhost',
user: 'myproject',
},
port: 8000,
secret: 'secret',
systemUsers: ['admin', 'anonymous'],

INITIAL CONTENT
myproject
└─ src
└─ profiles
└─ default
└─ documents
└─ schedule-2023.json
└─ schedule-2023.nick.json
└─ schedule-2023.documentation.json
└─ images
└─ rob.png
└─ steve.jpg

INITIAL CONTENT
profiles/default/documents/schedule-2023.json
{
"uuid": "405ca717-0c68-43a0-88ac-629a82658675",
"type": "Schedule",
"year": 2023,
"owner": "admin",
"workflow_state": "published"
}

INITIAL CONTENT
profiles/default/documents/schedule-2023.nick.json
{
"uuid": "605ca717-0c68-43a0-88ac-629a82658675",
"type": "Talk",
"title": "How to Build a Site Using Nick",
"description": "Nick is a nearly headless CMS written in Nod
"firstname": "Rob",
"lastname": "Gietema",
"bio": "Rob is a frontend webdeveloper for over 25 years. He
"picture": "/images/rob.png",
"length": "Long",
"level": "Beginner",
"owner": "robgietema",
"workflow_state": "approved"
}

VERSIONS
profiles/default/documents/schedule-2023.nick.json
{
"uuid": "605ca717-0c68-43a0-88ac-629a82658675",
"type": "Talk",
"title": "How to Build a Site Using Nick",
"description": "Nick is a nearly headless CMS written in Nod
"firstname": "Rob",
"lastname": "Gietema",
"bio": "Rob is a frontend webdeveloper for over 25 years. He
"picture": "/images/rob.png",
"length": "Long",
"level": "Beginner",
"owner": "robgietema",
"workflow_state": "approved"
"workflow_history": [
{

REDIRECTS
profiles/default/redirects.json
{
"purge": true,
"redirects": [{
"path": "/talks-2023",
"document": "405ca717-0c68-43a0-88ac-629a82658675"
}]
}

PERMISSION SYSTEM
Permissions
Roles (have permissions)
Groups (have roles)
Users (have roles, groups)
Local roles (user/group has a role on an object)
Local role permissions are inherited from the parent
Local role inheritence can be disabled per object
Workflows (have states and transitions)
States (have permissions per role)
Transitions (have permissions)

PERMISSIONS.JSON (GLOBAL)
{
"purge": false,
"permissions": [
{
"id": "View",
"title:i18n": "View"
},
{
"id": "Add",
"title:i18n": "Add"
},
{
"id": "Login",
"title:i18n": "Login"
},

PERMISSIONS.JSON (PROJECT)
{
"purge": false,
"permissions": [
{
"id": "Submit Talk",
"title:i18n": "Submit Talk"
},
{
"id": "Approve Talk",
"title:i18n": "Approve Talk"
}
]
}

ROLES.JSON (GLOBAL)
{
"purge": false,
"roles": [
{
"id": "Anonymous",
"title:i18n": "Anonymous",
"permissions": ["Login", "Register"]
},
{
"id": "Authenticated",
"title:i18n": "Authenticated",
"permissions": ["Logout", "Manage Preferences"]
},
{
"id": "Owner",

ROLES.JSON (PROJECT)
{
"purge": false,
"roles": [
{
"id": "Speaker",
"title:i18n": "Speaker",
"permissions": ["Submit Talk"]
},
{
"id": "Program Manager",
"title:i18n": "Program Manager",
"permissions": ["Approve Talk"]
}
]
}

USERS.JSON (PROJECT)
{
"purge": false,
"users": [
{
"id": "robgietema",
"password": "robgietema",
"fullname": "Rob Gietema",
"email": "robgietema@nickcms.org",
"groups": ["Speakers"]
},
{
"id": "admin",
"password": "admin",
"fullname": "Admin",
"email": "admin@nickcms.org",

GROUPS.JSON (PROJECT)
{
"purge": false,
"groups": [
{
"id": "Speakers",
"title:i18n": "Speakers",
"description:i18n": "",
"email": "",
"roles": ["Speaker"]
}
]
}

WORKFLOWS.JSON
{
"purge": false,
"workflows": [
{
"id": "talk_workflow",
"title:i18n": "Talk Workflow",
"description:i18n": "Workflow for talk submission and ap
"json": {
"initial_state": "submitted",
"states": {
"submitted": {
"title:i18n": "Submitted",
"description:i18n": "Talk has been submitted.",
"transitions": ["approve", "reject"],
"permissions": {

SHARING
myproject/src/profiles/default/documents/schedule-2023.json
{
"uuid": "405ca717-0c68-43a0-88ac-629a82658675",
"type": "Schedule",
"year": 2023,
"owner": "admin",
"workflow_state": "published",
"sharing": {
"users": [
{
"id": "robgietema",
"roles": ["Reader"]
}
],
"groups": [
{

VOCABULARIES
myproject
└─ src
└─ vocabularies
└─ talk-levels
└─ talk-levels.js
└─ index.js

VOCABULARY
/**
* Talk levels vocabulary.
* @module vocabularies/talk-levels/talk-levels
*/
import { objectToVocabulary } from '@robgietema/nick/src/helpe
/**
* Returns the talk levels vocabulary.
* @method talkLevels
* @returns {Array} Array of terms.
*/
export async function talkLevels(req, trx) {
// Return terms
return objectToVocabulary({

SRC/VOCABULARIES/INDEX.JS
/**
* Vocabularies.
* @module vocabularies
*/
import { talkLevels } from './talk-levels/talk-levels';
const vocabularies = {
'talk-levels': talkLevels,
};
export default vocabularies;

CONFIG
import vocabularies from './src/vocabularies';
connection: {
port: 5432,
host: 'localhost',
user: 'myproject',
},
port: 8000,
secret: 'secret',

PROFILE VOCABULARIES
myproject
└─ src
└─ profiles
└─ default
└─ vocabularies
└─ talk-length.json

PROFILE VOCABULARY
{
"id": "talk-length",
"title:i18n": "Talk Length",
"items": [
{ "title:i18n": "Short", "token": "Short" },
{ "title:i18n": "Long", "token": "Long" }
]
}

TALK.JSON
{
"id": "Talk",
"global_allow": false,
"allowed_content_types": [],
"schema": {
"fieldsets": [
{
"fields": ["title", "description", "length", "level"],
"id": "default",
}
],

CATALOG
Indexes
type (path, uuid, integer, date, text, string,
boolean, string[])
operators
Metadata
name
type
attribute

CATALOG.JSON (PROJECT)
{
"indexes": [
{
"name": "author",
"type": "string",
"attr": "author",
"title:i18n": "Author",
"description:i18n": "The author's name",
"group": "Text",
"enabled": false,
"sortable": true,
"operators": {
"string.contains": {
"title:i18n": "Contains",
"description:i18n": "",

BEHAVIORS (INDEXES)
myproject
└─ src
└─ behaviors
└─ author_index
└─ author_index.js
└─ total_time_index
└─ total_time_index.js
...

AUTHOR INDEX
/**
* Author index behavior.
* @module behaviors/author_index/author_index
*/
/**
* Author index behavior.
* @constant author_index
*/
export const author_index = {
/**
* Get author
* @method author
* @param {Object} trx Transaction object.
* @returns {String} author

TOTALTIME INDEX
/**
* Total time index behavior.
* @module behaviors/total_time_index/total_time_index
*/
import { map } from 'lodash';
/**
* Total time index behavior.
* @constant total_time_index
*/
export const total_time_index = {
/**
* Get total time
* @method totalTime

SRC/BEHAVIORS/INDEX.JS
/**
* Point of contact for behaviors.
* @module behaviors
*/
import { author_index } from './author_index/author_index';
import { id_title_from_year } from './id_title_from_year/id_ti
import { total_time_index } from './total_time_index/total_tim
const behaviors = {
author_index,
id_title_from_year,
total_time_index,
};

EVENTS
onBeforeAdd
onAfterAdd
onAfterModified
onBeforeCopy
...

EVENT FUNCTION
onBeforeAdd(context, trx, ...params)

EVENTS
myproject
└─ src
└─ events
└─ reindex_parent_on_modified
└─ reindex_parent_on_modified.js
└─ index.js

EVENT
/**
* Reindex parent on modified
* @module events/reindex_parent_on_modified
*/
const reindex_parent_on_modified = {
onAfterModified: async (context, trx) => {
if (context.type !== 'Talk') return;
// Fetch parent
if (!context._parent) {
await context.fetchRelated('_parent', trx);
}
// Reindex parent

SRC/EVENTS/INDEX.JS
/**
* Point of contact for events.
* @module events
* @example import events from './events';
*/
import events from '@robgietema/nick/src/events';
import reindex_parent_on_modified from './reindex_parent_on_mo
events.register(reindex_parent_on_modified);
export default events;

CONFIG
import events from './src/events';
import vocabularies from './src/vocabularies';
connection: {
port: 5432,
host: 'localhost',
user: 'myproject',
},
port: 8000,
secret: 'secret',

CONTROLPANELS
myproject
└─ src
└─ profiles
└─ default
└─ controlpanels
└─ venue.json

CONTROLPANEL
{
"id": "venue",
"title:i18n": "Venue",
"group": "General",
"schema": {
"fieldsets": [
{
"behavior": "plone",
"fields": [
"name",
"address",
"website"
],
"id": "default",
"title": "Default"

GETTINGS SETTINGS
import { Controlpanel } from '@robgietema/nick/src/models';
const controlpanel = await Controlpanel.fetchById('venue');
const config = controlpanel.data;
config.name
.address
.website

NAVIGATION CONTROLPANEL
{
"id": "navigation",
"title:i18n": "Navigation",
"group": "General",
"schema": {
"fieldsets": [
{
"fields": ["displayed_types", "additional_items"],
"id": "general",
"title": "General"
}
],
"properties": {
"displayed_types": {
"additionalItems": true,

OVERWRITE SETTINGS
{
"id": "navigation",
"data": {
"displayed_types": ["Folder", "Page", "Schedule"]
}
}

TESTING
myproject
└─ docs
└─ examples
└─ types
└─ schedule.req
└─ schedule.res
└─ src
└─ tests
└─ types
└─ types.test.js

SCHEDULE.REQ
GET /@types/Schedule HTTP/1.1
Accept: application/json
Authorization: Bearer eyJhbGciOiJIUzI1NiIsInR5cCI6IkpXVCJ9.eyJ

SCHEDULE.RES
HTTP/1.1 200 OK
Content-Type: application/json
{
"required": [
"year"
],
"fieldsets": [
{
"id": "default",
"title": "Default",
"fields": [
"year"
]
}

TYPES.TEST.JS
import app from '@robgietema/nick/src/app';
import { testRequest } from '@robgietema/nick/src/helpers';
describe('Types', () => {
it('should return the schedule type', () =>
testRequest(app, 'types/schedule'));
});

DOCS
myproject
└─ docs
└─ index.md
└─ types.md

INDEX.MD
---
layout: default
nav_exclude: true
---
# My Project
## Introduction
My awesome project!

TYPES.MD
---
nav_order: 1
permalink: /types
---
# Types
## Get the schema with GET
To get the schema of a content type, access the `/@types` endp
```
{% include_relative examples/types/schedule.req %}
```

QUESTIONS?
Want to implement a site using Nick? Talk to me!
slideshare.net/robgietema/nick-ploneconf-2023
github.com/robgietema/nick-example

How to Build a Site Using Nick

How to Build a Site Using Nick

Recommended

Recommended

More Related Content

Similar to How to Build a Site Using Nick

Similar to How to Build a Site Using Nick (20)

More from Rob Gietema

More from Rob Gietema (20)

Recently uploaded

Recently uploaded (20)

How to Build a Site Using Nick
