Evolution and Examples of Java Features, from Java 1.7 to Java 22

Yann-Gaël Guéhéneuc
(/jan/, he/il)
Work licensed under Creative Commons
BY-NC-SA 4.0 International
New Java
yann-gael.gueheneuc@concordia.ca
Version 0.22.1
2024/03/28

2/360
Patrick Naughton
Scott McNealy
Mike Sheridan James Gosling
1991

4/360
Naming
 Java
– 1995/05/23
– Language
 JDK (Java Development Kit)
– Compiler (Java Language Specification)
– VM (Java Virtual Machine Specification)
– APIs/Libraries (Java Class Libraries)

5/360
Process
 JCP: Java Community Process
– Established in 1998
– JSR-387 describes JCP v2.11

6/360
Documents
 JLSs: Java Language Specifications
– What is Java
 JSRs: Java Specification Requests
– Parts of the JCP
– New specifications and technologies
– JDK/OpenJDK
 JEPs: Java Enhancement Proposals
– Experimental ideas
– Could become JSRs
https://stackoverflow.com/questions/51282326/what-is-the-difference-or-relation-between-jls-jsr-and-jep

8/360
Too
Many
Features
Disclaimer
No
Preview
No
Incubator

9/360
Organisation
 Per release
– With some cross-references
 Three categories
– Language
– JVM
– APIs
Misc
+

10/360
Java 5
Java 6
2004/09/30
2006/12/11

12/360
Enums
 Special data type
– Declares/defines
variables set to
constants
interface PseudoEnum0 {
int YES = 0;
int NO = 1;
}
interface Interface1 {
public boolean foo();
}
enum RealEnum1 implements Interface1 {
YES {
public boolean foo() {
return true;
}
},
NO {
return false;
}
};
public boolean bar() {
return this.foo();
}
}

13/360
Enums
 Based on anonymous classes
System.out.println(RealEnum1.YES.bar());
System.out.println(RealEnum1.NO.bar());
System.out.print("Superclass: ");
System.out.println(RealEnum1.NO.getClass().getSuperclass());
System.out.print("Class: ");
System.out.println(RealEnum1.NO.getClass());
for (final Method method : RealEnum1.NO.getClass().getDeclaredMethods()) {
System.out.print("tMethods: ");
System.out.println(method);
}

14/360
Enums
 Based on anonymous classes
System.out.println(RealEnum1.YES.bar());
System.out.println(RealEnum1.NO.bar());
System.out.print("Superclass: ");
System.out.println(RealEnum1.NO.getClass().getSuperclass());
System.out.print("Class: ");
System.out.println(RealEnum1.NO.getClass());
for (final Method method : RealEnum1.NO.getClass().getDeclaredMethods()) {
System.out.print("tMethods: ");
System.out.println(method);
}
true
false
Superclass: class net.ptidej.newjava.enums.RealEnum1
Class: class net.ptidej.newjava.enums.RealEnum1$2
Methods: public boolean net.ptidej.newjava.enums.RealEnum1$2.foo()

15/360
Enums
Enum Simulated Enum
}
YES {
return true;
}
},
NO {
return false;
}
};
return this.foo();
}
}
}
abstract class SimulatedEnum1 implements Interface1 {
public static final SimulatedEnum1 YES =
new SimulatedEnum1() {
@Override
return true;
}
};
public static final SimulatedEnum1 NO =
@Override
return false;
}
};
private SimulatedEnum1() {
}
return this.foo();
}
}

16/360
Enums
Enum Simulated Enum
}
YES {
return true;
}
},
NO {
return false;
}
};
return this.foo();
}
}
}
@Override
return true;
}
};
@Override
return false;
}
};
}
return this.foo();
}
}
Instances of two
anonymous classes

17/360
Enums
Enum Simulated Enum
}
YES {
return true;
}
},
NO {
return false;
}
};
return this.foo();
}
}
Why private?
}
@Override
return true;
}
};
@Override
return false;
}
};
}
return this.foo();
}
}
Instances of two
anonymous classes

18/360
Enums
 More than just syntactic sugar
– Constants are constant expressions
final RealEnum3 v = // ...
switch (v) {
case YES:
System.out.println("YES");
break;
case NO:
System.out.println("NO");
break;
default:
throw // ...
}
final SimulatedEnum3 v1 = // ...
switch (v1) {
case SimulatedEnum3.YES:
break;
case SimulatedEnum3.NO:
break;
default:
throw // ...
}

19/360
Enums
 More than just syntactic sugar
– Constants are constant expressions
final RealEnum3 v = // ...
switch (v) {
case YES:
break;
case NO:
break;
default:
throw // ...
}
switch (v1) {
break;
break;
default:
throw // ...
}
case expressions must be constant expressions

20/360
Enums
 No work around the compilation error
– Some constants are not constant expressions
switch (v1) {
break;
break;
default:
throw // ...
}
final int v2 = // ...
switch (v2) {
case SimulatedEnum3.YES.constantID:
break;
case SimulatedEnum3.NO.constantID:
break;
default:
throw // ...
}
public final int constantID;

21/360
Java 7
2011/07/07
2011/07/07

23/360
Strings in switch
https://www.baeldung.com/java-switch
public String exampleOfSwitch(String animal) {
String result;
switch (animal) {
case "DOG" :
result = "domestic animal";
break;
case "CAT" :
result = "domestic animal";
break;
case "TIGER" :
result = "wild animal";
break;
default :
result = "unknown animal";
break;
}
return result;
}

24/360
try With Resources
 New interfaces
– java.lang.Closeable
– java.lang.AutoCloseable
https://www.baeldung.com/java-try-with-resources
try (final Scanner scanner = new Scanner(new File("test.txt"))) {
while (scanner.hasNext()) {
System.out.println(scanner.nextLine());
}
}
catch (final FileNotFoundException fnfe) {
fnfe.printStackTrace();
}

25/360
Diamond Operator <>
https://www.baeldung.com/java-diamond-operator
List<String> cars = new ArrayList<String>();
List<String> cars = new ArrayList<>();
vs.

26/360
Vargs in Method Declaration
https://www.baeldung.com/java-varargs
https://www.baeldung.com/java-varargs
public String format() {
// ...
}
public String format(String value) {
//...
}
public String format(String val1, String val2) {
// ...
}
public String formatWithVarArgs(String... values) {
System.out.println(values[0]);
// ...
}
vs.

27/360
Binary Integer Literals
https://www.geeksforgeeks.org/java-program-to-illustrate-use-of-binary-literals/
// Byte type Binary Literal
byte a1 = 0b011;
// Short type Binary Literal
short b1 = 0b101;
// Int type Binary literal
int c1 = 0b011;
// Long type Binary literal
long d1 = 0b0000011111100011;

28/360
Underscores in Numeric Literals
int i = 12_34_56;
System.out.println(i);
https://www.geeksforgeeks.org/using-underscore-numeric-literals-java/

29/360
Multiple Exception Types
 Multiple exception types
 Multiple exceptions rethrown
with improved type checking

30/360
Multiple Exception Types
public static void main(final String[] args) {
try {
Example1.rethrow("abc");
}
catch (final FirstException | SecondException e) {
// Below assignment would throw a compile-time exception, e is implicitly final
// e = new Exception();
System.out.println(e.getMessage());
}
}
private static void rethrow(final String s) throws FirstException, SecondException {
try {
if (s.equals("First")) throw new FirstException("First");
else throw new SecondException("Second");
}
catch (final Exception e) {
// Below assignment would disable improved rethrow exception type checking
// e = new ThirdException();
throw e;
}
}
private static class FirstException extends Exception {
public FirstException(String msg) {
super(msg);
}
}
// ...

32/360
JSR-292: invokedynamic
 invokestatic, for class methods
 invokevirtual, for instance methods
 invokeinterface, for interface methods
 invokespecial, for instance initialisation,
superclass, and private methods

33/360
Gilad Bracha, 2005

34/360
 invokedynamic indicates that a dynamic
language run-time specific call occurs
 The call occurs through MethodHandle(s)
https://www.baeldung.com/java-method-handles
MethodHandles.Lookup publicLookup = MethodHandles.publicLookup();
MethodType mt = MethodType.methodType(String.class, char.class, char.class);
MethodHandle replaceMH = publicLookup.findVirtual(String.class, "replace", mt);
String output = (String) replaceMH.invoke("jovo", 'o', 'a');

36/360
JSR-166: Concurrency Utilities
 Concurrency utilities under JSR 166
 java.util.concurrent wants to be for
concurrency what java.util.Collections
is for collections
 With some JVM support
– Timing
– Atomics
– …
https://gee.cs.oswego.edu/dl/concurrency-interest/jsr166-slides.pdf

37/360
https://www.uml-diagrams.org/java-7-concurrent-uml-class-diagram-example.html

38/360

39/360

40/360
final Runnable runnable1 = new RunnableExample("executor.execute(...)");
final ExecutorService executor = Executors.newFixedThreadPool(10);
executor.execute(runnable1);
final Runnable runnable2 = new RunnableExample("new Thread(...)");
new Thread(runnable2).start();
vs.

41/360
class ImageRenderer {
Image render(final byte[] raw) {
return // ...
}
}
public class Example2 {
public void display(final byte[] raw) throws InterruptedException, ExecutionException {
final ImageRenderer renderer = new ImageRenderer();
final Future<Image> image = executor.submit(new Callable<Image>() {
public Image call() {
return renderer.render(raw);
}
});
drawBorders(); // do other things ...
drawCaption(); // ... while executing
drawImage(image.get()); // use Future
}
// ...

42/360
public void run() {
synchronized (this.resource) {
this.resource.doSomething();
}
this.resource.doLogging();
}
public void run() {
try {
if (this. lock.tryLock(10, TimeUnit.SECONDS)) {
this.resource.doSomething();
}
}
catch (final InterruptedException exception) {
exception.printStackTrace();
}
finally {
this.lock.unlock();
}
this.resource.doLogging();
}
vs.
https://www.digitalocean.com/com
munity/tutorials/java-lock-example-
reentrantlock

43/360
https://www.geeksforgeeks.org/semaphore-in-java/
private final Semaphore semaphore;
private void connect(final String user)
throws InterruptedException {
System.out.println(getCurrentDateTime()
+ " : " + user + " waiting sem");
this.semaphore.acquire();
+ " : " + user + " acquired sem");
Thread.sleep(1000); // Some work...
this.semaphore.release();
+ " : " + user + " released sem");
}
https://mkyong.com/java/java-semaphore-examples/

44/360
https://www.geeksforgeeks.org/atomic-variables-in-java-with-examples/
class Counter extends Thread {
private final AtomicInteger count;
public Counter() {
this.count = new AtomicInteger();
}
public void run() {
final int max = 10_000_000;
for (int i = 0; i < max; i++) {
count.addAndGet(1);
}
}
public int getCount() {
return this.count.get();
}
}

45/360
JSR-203: New File I/O Library
 Extensive File I/O API
 Socket channel API
 Asynchronous I/O API

46/360
 Extensive File I/O API
https://www.baeldung.com/java-nio2-file-visitor
public class Example1FileVisitor {
public static void main(final String[] args) throws IOException {
final Path startPath = Paths.get("D:DocumentsTutorials220926 - New Java");
final String fileName = "Example1FileVisitor.java";
final FileVisitorImpl visitor = new FileVisitorImpl(fileName, startPath);
Files.walkFileTree(startPath, visitor);
}
}

47/360
class FileVisitorImpl implements FileVisitor<Path> {
private final String fileName;
private final Path startPath;
public FileVisitorImpl(final String aFileName, final Path aStartPath) {
this.fileName = aFileName;
this.startPath = aStartPath;
}
@Override
public FileVisitResult preVisitDirectory(final Path aPath, final BasicFileAttributes someAttributes) {
return FileVisitResult.CONTINUE;
}
@Override
public FileVisitResult visitFile(final Path aPath, final BasicFileAttributes someAttributes) {
final String fileName = aPath.getFileName().toString();
if (fileName.equals(this.fileName)) {
return FileVisitResult.TERMINATE;
}
}
@Override
public FileVisitResult visitFileFailed(final Path aPath, final IOException anIOException) {
}
@Override
public FileVisitResult postVisitDirectory(final Path aPath, final IOException anIOException) {
try {
if (Files.isSameFile(aPath, this.startPath)) {
return FileVisitResult.TERMINATE;
}
} catch (final IOException e) {
e.printStackTrace();
}
}
}

48/360
 Socket channel API – Client
public static void client() throws IOException {
final ServerSocketChannel serverSocket = ServerSocketChannel.open();
serverSocket.socket().bind(new InetSocketAddress(9000));
final SocketChannel client = serverSocket.accept();
System.out.println("Connection set: " + client.getRemoteAddress());
final Path path = Paths.get("D:DocumentsTutorials220926 - New JavaReceivedFile.txt");
final FileChannel fileChannel = FileChannel.open(
path,
EnumSet.of(StandardOpenOption.CREATE, StandardOpenOption.TRUNCATE_EXISTING,
StandardOpenOption.WRITE));
final ByteBuffer buffer = ByteBuffer.allocate(1024);
while (client.read(buffer) > 0) {
buffer.flip();
fileChannel.write(buffer);
buffer.clear();
}
fileChannel.close();
System.out.println("File received");
client.close();
}
https://www.tutorialspoint.com/java_nio/java_nio_socket_channel.htm

49/360
 Socket channel API – Server
public static void server() throws IOException {
final SocketChannel server = SocketChannel.open();
final SocketAddress socketAddr = new InetSocketAddress("localhost", 9000);
server.connect(socketAddr);
final Path path = Paths.get("D:DocumentsTutorials220926 - New JavaPatterns.txt");
final FileChannel fileChannel = FileChannel.open(path);
final ByteBuffer buffer = ByteBuffer.allocate(1024);
while (fileChannel.read(buffer) > 0) {
buffer.flip();
server.write(buffer);
buffer.clear();
}
fileChannel.close();
System.out.println("File sent");
server.close();
}

50/360
 Socket channel API – Main
final Runnable runnableClient = new Runnable() {
public void run() {
try {
Example2SocketChannel.client();
}
}
};
final Runnable runnableServer = new Runnable() {
public void run() {
try {
Example2SocketChannel.server();
}
}
};
executor.execute(runnableClient);
executor.execute(runnableServer);
}

51/360
 Asynchronous I/O API
“The asynchronous channel APIs were
introduced into the existing
java.nio.channels package […] by
prefixing […] with Asynchronous”

52/360
Translucent and Shaped Windows
 Improves Java Swing
 Allow new, nicer themes
https://ateraimemo.com/Swing/TranslucentFrame.html
Window.setShape(Shape s)
Window.setOpacity(float f)

53/360
Network Protocols
 Network protocols
– Stream Control
Transport Protocol
(SCTP)
– Sockets Direct
Protocol (SDP)
 In packages
– com.sun.nio.sctp
– com.sun.sdp
https://www.oracle.com/technical-resources/articles/javase/sctp.html
final SctpServerChannel ssc =
SctpServerChannel.open();
final InetSocketAddress serverAddr = // ...
ssc.bind(serverAddr);
while (true) {
final SctpChannel sc = ssc.accept();
final Date today = new Date();
cbuf.put(USformatter.format(today)).flip();
encoder.encode(cbuf, buf, true);
buf.flip();
messageInfo.streamNumber(FUS_STREAM);
sc.send(buf, messageInfo);
buf.clear();
cbuf.clear();
cbuf.put(FRformatter.format(today)).flip();
encoder.encode(cbuf, buf, true);
buf.flip();
messageInfo.streamNumber(FR_STREAM);
sc.send(buf, messageInfo);
buf.clear();
cbuf.clear();
// ...

54/360
Updates to XML and Unicode
 New system property named
org.jcp.xml.dsig.secureValidation
 New XML Processing Limits
 Regular Expression pattern matching
supports Unicode 6.0.0
– Major version of the Unicode Standard

57/360
default, static Interface Methods
public interface IA {
int foo();
default int bar() {
return 42;
}
}
final IA anIA = new IA() {
public int foo() {
return 0;
}
};
System.out.println(anIA.foo());
System.out.println(anIA.bar());
final IA anotherIA = new IA() {
public int foo() {
return IA.super.bar();
}
public int bar() {
return 0;
}
};
System.out.println(anotherIA.foo());
System.out.println(anotherIA.bar());
}

58/360
int foo();
default int bar() {
return 42;
}
}
public int foo() {
return 0;
}
};
public int foo() {
return IA.super.bar();
}
public int bar() {
return 0;
}
};
}
0
42
42
0

59/360
 https://stackoverflow.c
om/questions/512877/
why-cant-i-define-a-
static-method-in-a-
java-interface
int foo();
static int bar() {
return 42;
}
}
public class A {
int foo() {
return 0;
}
static int bar() {
return 42;
}
}
public int foo() {
return 0;
}
};
final A anA = new A();
System.out.println(anA.foo());
System.out.println(anA.bar());
}

60/360
static-method-in-a-
java-interface
int foo();
static int bar() {
return 42;
}
}
public class A {
int foo() {
return 0;
}
static int bar() {
return 42;
}
}
public int foo() {
return 0;
}
};
}

61/360
static-method-in-a-
java-interface
int foo();
static int bar() {
return 42;
}
}
public class A {
int foo() {
return 0;
}
static int bar() {
return 42;
}
}
public int foo() {
return 0;
}
};
}
System.out.println(IA.bar());

62/360
JSR-335, JEP-126: λ Expressions
 λ Expressions
interface Applicable<T, R> {
public R apply(final T aParameter);
}
final Applicable<String, Integer> strlen = new Applicable<>() {
@Override
public Integer apply(final String aParameter) {
return aParameter.length();
}
};
System.out.println(strlen.apply("Hello, World!"));
}
https://jenkov.com/tutorials/java-functional-programming/functional-interfaces.html

63/360



}
@Override
}
};
}

64/360
 Lots of boilerplate code
 Difficult to understand
 Not common in the libraries
}
@Override
}
};
}

65/360
 Solution
– Simple syntactic sugar
– Set of functional interfaces
– Libraries using these interfaces

66/360
 Solution

67/360
 Solution
}
final Applicable<String, Integer> strlen = (paramter) -> paramter.length();
}

68/360
 Solution
}
final Applicable<String, Integer> strlen = (paramter) -> paramter.length();
}
final Applicable<String, Integer> strlen = String::length;
}

69/360
 Solution
http://blog.orfjackal.net/2014/07/java-8-functional-interface-naming-guide.html

70/360
 Solution
http://blog.orfjackal.net/2014/07/java-8-functional-interface-naming-guide.html

71/360
 Solution
https://blogs.oracle.com/javamagazine/post/functional-programming-in-java-part-1-lists-lambdas-and-method-references

72/360
 Solution
https://blogs.oracle.com/javamagazine/post/functional-programming-in-java-part-1-lists-lambdas-and-method-references
final List<String> friends = Arrays.asList("Rick Deckard", "Roy Batty", "Harry
Bryant", "Hannibal Chew", "Gaff", "Holden", "Leon Kowalski", "Taffey Lewis",
"Pris", "Rachael", "J.F. Sebastian", "Dr. Eldon Tyrell", "Zhora", "Hodge",
"Mary");
for (int i = 0; i < friends.size(); i++) {
System.out.println(friends.get(i));
}
for (String name : friends) {
System.out.println(name);
}
friends.forEach(new Consumer<String>() {
public void accept(final String aName) { System.out.println(aName); }});
friends.forEach((final String name) -> System.out.println(name));
friends.forEach((name) -> System.out.println(name));
friends.forEach(name -> System.out.println(name));
friends.forEach(System.out::println);
friends.stream().map(String::toUpperCase).forEach(
name -> System.out.print(name + " "));
System.out.println();
final List<String> namesStartingWithN = friends.stream().
filter(name -> name.startsWith("R")).collect(Collectors.toList());
System.out.println(namesStartingWithN);

73/360
 But code duplication!
https://blogs.oracle.com/javamagazine/post/functional-programming-
in-java-part-2-lambda-reuse-lexical-scoping-and-closures-and-reduce
output = friends1.stream().filter(name -> name.startsWith("R")).collect(Collectors.toList());
System.out.println(output);
output = friends2.stream().filter(name -> name.startsWith("R")).collect(Collectors.toList());
final Predicate<String> predicate = name -> name.startsWith("R");
output = friends1.stream().filter(predicate).collect(Collectors.toList());
output = friends2.stream().filter(predicate).collect(Collectors.toList());
vs.

74/360
// Lexical scoping and closure
output = friends1.stream().filter(checkIfStartsWith("R")).collect(Collectors.toList());
output = friends2.stream().filter(checkIfStartsWith("P")).collect(Collectors.toList());
// Narrower lexical scoping
final Function<String, Predicate<String>> startsWithLetter = letter -> (name ->
name.startsWith(letter));
output = friends1.stream().filter(startsWithLetter.apply("R")).collect(Collectors.toList());
output = friends2.stream().filter(startsWithLetter.apply("P")).collect(Collectors.toList());
vs.

75/360
output = friends1.stream().filter(startsWithLetter("R")).collect(Collectors.toList());
output = friends2.stream().filter(startsWithLetter("P")).collect(Collectors.toList());
vs.

76/360
https://forum.devtalk.com/t/functional-programming-in-java-second-
edition-p-35-refactoring-to-narrow-the-scope-code/105447
output = friends1.stream().filter(startsWithLetter("R")).collect(Collectors.toList());
output = friends2.stream().filter(startsWithLetter("P")).collect(Collectors.toList());
vs.

77/360
JSR-308, JEP-104: Type Annotations
 Allow pluggable type systems
 Help enforce stronger typing
final String aString = null;
final String anotherString = aString;
System.out.println(anotherString);
}
}

78/360
}
}
final @NonNull String anotherString = aString;
}
}

79/360
}
}
}
}
Null type mismatch: required
'@NonNull String' but the
provided value is null

80/360
}
}
}
}
final String aString = "";
}
}
Null type mismatch: required
'@NonNull String' but the
provided value is null

81/360
class A {
String getString() {
return null;
}
}
public static void foo1() {
final A a = new A();
final String aString = a.getString();
}
if (aString != null) {
}
}
}

82/360
class A {
String getString() {
return null;
}
}
}
if (aString != null) {
}
}
}
Null type safety […] needs
unchecked conversion to
conform to '@NonNull String'

83/360
 “The Checker Framework includes compiler
plug-ins ("checkers") that find bugs or verify
their absence. It also permits you to write
your own compiler plug-ins.”
– https://checkerframework.org/tutorial/

84/360
Unsigned Integer Arithmetic
 Comparison
 Division/Modulo
 Parsing
 Formatting
https://www.baeldung.com/java-unsigned-arithmetic
public static void main(String[] args) {
final int positive = Integer.MAX_VALUE;
final int negative = Integer.MIN_VALUE;
final int signedComparison = Integer.compare(positive, negative);
if (signedComparison > 0) {
System.out.println("Positive > negative (signed comparison)");
}
final int unsignedComparison = Integer.compareUnsigned(positive, negative);
if (unsignedComparison < 0) {
System.out.println("Positive NOT > negative (unsigned comparison)");
}
}
}

85/360
JEP-120: Repeating Annotations
 “Annotations, a form of metadata, provide
data about a program that is not part of the
program [and] have no direct effect on the
operation of the code they annotate.”
https://docs.oracle.com/javase/tutorial/java/annotations/

86/360
 “Annotations, a form of metadata, provide
data about a program that is not part of the
program [and] have no direct effect on the
operation of the code they annotate.”
https://docs.oracle.com/javase/tutorial/java/annotations/

87/360
https://rolyhewage.medium.com/type-annotations-repeating-annotations-in-java-722073df9f99
@Retention(RetentionPolicy.RUNTIME)
@interface ScheduleNonRepeatable1 {
String dayOfMonth() default "First";
String dayOfWeek() default "Mon";
int hour() default 12;
}
@ScheduleNonRepeatable1(dayOfWeek = "Fri", hour = 23)
final Example1 example1 = new Example1();
final Annotation annotation = example1.getClass().
getAnnotation(ScheduleNonRepeatable1.class);
System.out.println(annotation);
}
}

88/360
}
}
}
@ScheduleNonRepeatable1(hour=23, dayOfMonth="First", dayOfWeek="Fri")

89/360
}
@ScheduleNonRepeatable2(dayOfMonth = "last")
}
}

90/360
}
@ScheduleNonRepeatable2(dayOfMonth = "last")
}
}
Duplicate annotation of
non-repeatable type
@ScheduleNonRepeatable2

91/360
@interface Schedules {
ScheduleRepeatable[] value();
}
@Repeatable(Schedules.class)
@interface ScheduleRepeatable {
}
@ScheduleRepeatable(dayOfMonth = "last")
@ScheduleRepeatable(dayOfWeek = "Fri", hour = 23)
getAnnotation(Schedules.class);
}
}

92/360
@interface Schedules {
ScheduleRepeatable[] value();
}
@Repeatable(Schedules.class)
@interface ScheduleRepeatable {
}
@ScheduleRepeatable(dayOfMonth = "last")
@ScheduleRepeatable(dayOfWeek = "Fri", hour = 23)
getAnnotation(Schedules.class);
}
}
@Schedules({@ScheduleRepeatable(hour=12, dayOfMonth="last", dayOfWeek="Mon"),
@ScheduleRepeatable(hour=23, dayOfMonth="First", dayOfWeek="Fri")})

94/360
JEP-178: Statically-linked JNI
Libraries
 Native programs that embed the JRE
 Java programs running in environments
without shared libraries
 Enable developers to package a Java run-
time, native code, and Java code together
into a single binary

95/360
JEP-122: Permanent Generation
Removal
 “Automatic garbage
collection is [..]
identifying which
objects are in use and
[…] deleting the
unused objects.”
 Remove Permanent
Generation
– No more size tuning
https://openjdk.org/jeps/122

97/360
JEP-174: Nashorn JS Engine
 Successor of Mozilla’s Rhino
 100% in ECMAScript v5.1 test suite
 Java 8: Introduced
 Java 11: Deprecated
 Java 15: Removed

98/360
JEP-174: Nashorn JS Engine
 https://github.com/openjdk/nashorn
https://www.baeldung.com/java-nashorn
final ScriptEngine engine = new ScriptEngineManager().getEngineByName("Nashorn");
final Bindings bindings = engine.createBindings();
bindings.put("name", "Nashorn");
result = engine.eval("var greeting = 'hello world' + name;" + "print(greeting);" + "greeting");
System.out.println(result);
final Invocable invocable = (Invocable) engine;
engine.eval("function composeGreeting(name) {" + "return 'Hello ' + name" + "}");
result = invocable.invokeFunction("composeGreeting", "Nashorn");
result = engine.eval("var HashMap = Java.type('java.util.HashMap’);"
+ "var map = new HashMap();"
+ "map.put('hello', 'world');" + "map");

99/360
JSR-310, JEP-150: Date, Time API
 Need to manipulate dates and times
 Disparate APIs, missing features
– Set time to midnight for a date without a time
 Complete terminology
 Complete, cohesive implementation
– java.time.*

101/360
JEP-153: JavaFX Applications
 Three “types” of programs
– Class files
– JAR files
– JavaFX
 Enhance the java command-line to launch
JavaFX programs

104/360
Private Interface Methods
int foo();
default int bar() {
return this.bar1();
}
private int bar1() {
return 42;
}
}
public int foo() {
return 0;
}
};
public int foo() {
return IA.super.bar1();
}
public int bar() {
return 0;
}
};
}

105/360
Private Interface Methods
int foo();
default int bar() {
return this.bar1();
}
private int bar1() {
return 42;
}
}
public int foo() {
return 0;
}
};
public int foo() {
return IA.super.bar1();
}
public int bar() {
return 0;
}
};
}
0
42
42
0

106/360
JSR-376: Modularization
 JSR-376: Java Platform Module System,
part of Project Jigsaw
– Ease library construction, maintenance
– Security, maintainability of Java (and JDK)
– Allow scaling down programs for small devices
– Improve program compilation and loading times
https://openjdk.org/projects/jigsaw/

107/360
 JEP-200: The Modular JDK
 JEP-201: Modular Source Code
 JEP-220: Modular Run-time Images
 JEP-260: Encapsulate Most Internal APIs
 JEP-261: Module System
 JEP-282: jlink: The Java Linker
 JSR 376: Java Platform Module System

108/360
 Classpath / JARs Hell
 Version conflicts
 Large Monolithic JDK
 Security Problems
https://www.geeksforgeeks.org/jpms-java-platform-module-system/

109/360
– Cf. DLL Hell, no versions, one directory
– One, long list of JAR files
• Run-time missing dependencies
• Order of declaration (shadowing)

110/360
– E.g., in Java v1.4.2, RT.jar is 21.8 MB (!)

111/360
– Implementation classes must be public
– Cannot control access to these classes
– padl.kernel vs. padl.kernel.impl

112/360
 A module is a “package of packages”
– With one module descriptor
– With own resources (data)
 A module descriptor
– Domain Specific Language
– exports, module, open, opens, provides,
requires, to, transitive, uses, and with

113/360
Raoul-Gabriel Urma, Mario Fusco, Alan Mycroft ; Modern Java in Action ; Manning, 2018 (Chapter 14)
module com.example.foo {
requires transitive com.example.foo.network;
requires static com.example.foo.http;
requires java.logging;
exports com.example.foo.bar;
exports com.example.foo.internal to
com.example.foo.probe;
opens com.example.foo.quux;
opens com.example.foo.internal to
com.example.foo.network,
uses com.example.foo.spi.Intf;
provides com.example.foo.spi.Data with
com.example.foo.Impl;
}

114/360
Raoul-Gabriel Urma, Mario Fusco, Alan Mycroft ; Modern Java in Action ; Manning, 2018 (Chapter 14)
}

115/360
 Declaration of module
com.example.foo
 Dependencies on
three other modules
– transitive: client
modules also can
access that module
– static: at compile-time,
option at run-time
}

116/360
 (Qualified) exports to
other, client modules
– Public types accessible
to all client modules
– Or only to types in
com.example.foo.probe
}

117/360
 (Qualified) opening to
other, client modules
at run-time only
– Public types accessible
to all client modules
– Or only to types in com.
example.foo.network or
com.example.foo.probe
– Allows introspection
}

118/360
}
 Service consumer
– Interface/abstract class
com.example.foo.spi.Intf
 Service provider
– Interface/abstract class
com.example.foo.spi.Data
– With concrete class
com.example.foo.Impl

119/360
 modularisation.Client
– Can access any public
type at compile-time
and at run-time
– Can access some
protected/private
data with introspection
 internal.Client
– Cannot access
HiddenImplementation

120/360
 modularisation.Client
– Can access any public
type at compile-time
and at run-time
– Can access some
protected/private
data with introspection
 internal.Client
– Cannot access
HiddenImplementation
Package-protected
Class (not public!)

121/360
final Interface aki = new Implementation();
aki.foo();
System.out.println("Call on public implementation: ");
final Class<? extends Interface> implementation1 = Class
.forName(“....impl.Implementation").asSubclass(Interface.class);
final Interface aki1 = implementation1.getDeclaredConstructor().newInstance();
final Method[] methods1 = implementation1.getDeclaredMethods();
for (final Method method : methods1) {
try {
method.setAccessible(true);
method.invoke(aki1, new Object[0]);
} catch (final RuntimeException e) {
System.out.println(e.getMessage());
}
}
final Class<? extends Interface> implementation2 = Class
.forName(“....impl.HiddenImplementation").asSubclass(Interface.class);
final Interface aki2 = implementation2.getDeclaredConstructor().newInstance();
final Method[] methods2 = implementation2.getDeclaredMethods();
for (final Method method : methods2) {
// Same code

122/360
 The client code has access to the fields and
methods in all public types, even if private
Direct call: Implementation.bar()
Call on public implementation:
bar: Implementation.bar()
foo: Implementation.bar()
Call on hidden implementation:
Exception in thread "main" java.lang.IllegalAccessException: class
net.ptidej.modularisation.Client cannot access a member of class
net.ptidej.modularisation.kernel.impl.HiddenImplementation with package
access
...

123/360
 The client code has access to the fields and
methods in all public types, even if private
Exception in thread "main" java.lang.IllegalAccessException: class
net.ptidej.modularisation.Client cannot access a member of class
net.ptidej.modularisation.kernel.impl.HiddenImplementation with package
access
...
Including the
private method

124/360
 Client
 Provider
module ModularizationWithModulesClient1 {
requires ModularizationWithModulesLibrary1;
}
module ModularizationWithModulesLibrary1 {
exports net.ptidej.modularisation.kernel;
exports net.ptidej.modularisation.kernel.impl;
}

125/360
 Client (not a module)
 Client (module)
Exception in thread "main" java.lang.IllegalAccessException: class net.ptidej.modularisation.Client
cannot access a member of class net.ptidej.modularisation.kernel.impl.HiddenImplementation with
package access
bar: Unable to make private void net.ptidej.modularisation.kernel.impl.Implementation.bar()
accessible: module ModularizationWithModulesLibrary1 does not "opens
net.ptidej.modularisation.kernel.impl" to module ModularizationWithModulesClient1
(in module ModularizationWithModulesClient1) cannot access a member of class
net.ptidej.modularisation.kernel.impl.HiddenImplementation (in module
ModularizationWithModulesLibrary1) with package access

126/360
 Client (module)
package access
Non-module can still
access private methods

127/360
 Client (module)
package access
Non-module can still
access private methods
Modules cannot access
private/package data

128/360
 Client
 Provider
module ModularizationWithModulesClient2 {
requires ModularizationWithModulesLibrary2;
uses net.ptidej.modularisation.kernel.Interface;
}
module ModularizationWithModulesLibrary2 {
exports net.ptidej.modularisation.kernel;
provides
net.ptidej.modularisation.kernel.Interface with
net.ptidej.modularisation.kernel.impl.Implementation;
}

129/360
 Client implementation
 Client output
Implementation.bar()
(in module ModularizationWithModulesClient2) cannot access class
net.ptidej.modularisation.kernel.impl.Implementation (in module ModularizationWithModulesLibrary2)
because module ModularizationWithModulesLibrary2 does not export
net.ptidej.modularisation.kernel.impl to module ModularizationWithModulesClient2
final ServiceLoader<Interface> providers = ServiceLoader.load(Interface.class);
final Interface aki = providers.findFirst().orElse(null);
aki.foo();

130/360
 Client implementation
 Client output
Implementation.bar()
(in module ModularizationWithModulesClient2) cannot access class
net.ptidej.modularisation.kernel.impl.Implementation (in module ModularizationWithModulesLibrary2)
because module ModularizationWithModulesLibrary2 does not export
net.ptidej.modularisation.kernel.impl to module ModularizationWithModulesClient2
No access to data not
exported/provided,
even if public!
final ServiceLoader<Interface> providers = ServiceLoader.load(Interface.class);
final Interface aki = providers.findFirst().orElse(null);
aki.foo();

131/360
https://www.baeldung.com/java-illegal-reflective-access
 Backward compatibility

132/360
https://docs.oracle.com/javase%2F9%2Fdocs%2Fapi%2F%2F/overview-summary.html

133/360
https://docs.oracle.com/javase%2F9%2Fdocs%2Fapi%2F%2F/java/lang/Module.html

134/360
 Relation to OSGi
– Open Service Gateway Initiative
• From 05/2000, latest 12/2020
– Eclipse Foundation open-source project
– Framework for developing and deploying
• Modular programs and libraries
• IoT and other constrained devices
https://www.techtarget.com/searchnetworking/definition/OSGi

135/360
OSGi (Bundles)
 Several class loaders
– Cannot be used for the JDK
– Allow “duplicate” packages
– Allow multiple versions
 Visibility
JPMS (Modules)
 One class loader
– Can be used in the JDK
– Disallow same packages
– No versioning
 Accessibility
https://www.infoq.com/articles/java9-osgi-future-modularity/, https://www.infoq.com/articles/java9-osgi-future-modularity-
part-2/, https://www.baeldung.com/java-illegal-reflective-access, https://en.wikipedia.org/wiki/OSGi

136/360
OSGi (Bundles)
 “[B]uild dependencies and
runtime dependencies can
and often do differ”
JPMS (Modules)
 “[T]he module system
should […] work [same] at
compile time, run time…”
Export-Package: org.example.foo;
version=1.0.1, org.example.bar;
version=2.1.0
Import-Package: org.example.foo;
version='[1,2)', org.example.bar;
version='[2.0,2.1)'
module A {
exports org.example.foo;
exports org.example.bar;
}
module B {
require A;
}
https://www.infoq.com/articles/java9-osgi-future-modularity/, https://www.infoq.com/articles/java9-osgi-future-modularity-
part-2/, https://www.baeldung.com/java-illegal-reflective-access, https://en.wikipedia.org/wiki/OSGi

137/360
JEP-213: Milling Project Coin
 From Java 7
– Allow @SafeVargs on private instance methods
– Allow effectively-final variables as resources in the try-
with-resources statement
– Allow diamond with anonymous classes in some cases
 From Java 8
– Remove underscore as legal identifier names
 In Java 9
– Support for private methods in interfaces

139/360
 Nothing to mention, so much
work went into modularisation

141/360
Collection Factory Methods
 No null values
 No modification
– Run-time exception
final List<String> list = List.of("Rick Deckard", "Roy Batty", "Harry Bryant", "Hannibal
Chew", "Gaff", "Holden", "Leon Kowalski", "Taffey Lewis", "Pris", "Rachael", "J.F.
Sebastian", "Dr. Eldon Tyrell", "Zhora", "Hodge", "Mary");
System.out.println(list);
list.add("Paul Atreides");
}
}

142/360
Collection Factory Methods
 No null values
 No modification
– Run-time exception
final List<String> list = List.of("Rick Deckard", "Roy Batty", "Harry Bryant", "Hannibal
Chew", "Gaff", "Holden", "Leon Kowalski", "Taffey Lewis", "Pris", "Rachael", "J.F.
Sebastian", "Dr. Eldon Tyrell", "Zhora", "Hodge", "Mary");
System.out.println(list);
list.add("Paul Atreides");
}
}
[Rick Deckard, Roy Batty, Harry Bryant, [...] Tyrell, Zhora, Hodge, Mary]
Exception in thread "main" java.lang.UnsupportedOperationException
at java.base/java.util.ImmutableCollections.uoe(ImmutableCollections.java:142)
at [...]
at net.ptidej.newjava.collectionfactories.Example1.main(Example1.java:11)

143/360
JavaDB Removal
 JavaDB was a repackaging of Apache Derby
– Relational database
– Open-source
– Entirely in Java
– Embedded JDBC driver

144/360
JEP-254: Compact Strings
Problem and Solution
 More space-efficient
internal representation
– Not about using UTF-8
 From a UTF-16 char
array to a byte array
with an encoding flag
– ISO-8859-1/Latin-1 (1 byte
per char) or UTF-16 (2 bytes)
– String-related classes and
HotSpot intrinsic operations
Consequences
 Reduction in memory
footprint
 Substantial reductions of
GC activity
 Minor performance
regressions in some
corner cases

145/360
JEP-263: HiDPI Graphics
 Java programs sized and
rendered based on pixels
 HiDPI displays can have 2
to 3 times higher pixel
densities
 Windows Direct2D APIs
 Linux GTK+ 3 libraries
https://stackoverflow.com/questions/52519777/java-swing-app-looks-tiny-on-high-dpi-screen-when-it-should-be-scaled-to-normal

146/360
JEP-266: More on Concurrency
 “[A]synchronous stream processing with
non-blocking back pressure”
– https://www.reactive-streams.org/
https://www.baeldung.com/java-9-reactive-streams
// Given
final SubmissionPublisher<String> publisher = new SubmissionPublisher<>();
final EndSubscriber<String> subscriber = new EndSubscriber<>();
final List<String> items = List.of("1", "x", "2", "x", "3", "x");
// When
publisher.subscribe(subscriber);
items.forEach(publisher::submit);
publisher.close();
// Then
Awaitility.await().atMost(1000, TimeUnit.MILLISECONDS)
.until(() -> subscriber.consumedElements.containsAll(items));

147/360
JEP-268: XML Catalogs
 OASIS XML Catalogs standard, v1.1
– Map XML external identifiers into (local) URIs
 Java API
– javax.xml.catalog.*
<?xml version="1.0"?>
<!DOCTYPE catalog
PUBLIC "-//OASIS//DTD Entity Resolution XML Catalog V1.0//EN"
"http://www.oasis-open.org/committees/entity/release/1.0/catalog.dtd">
<catalog xmlns="urn:oasis:names:tc:entity:xmlns:xml:catalog" prefer="public">
<public publicId="-//W3C//DTD XHTML 1.0 Strict//EN"
uri="dtd/xhtml1/xhtml1-strict.dtd"/>
<public publicId="-//W3C//DTD XHTML 1.0 Transitional//EN"
uri="dtd/xhtml1/xhtml1-transitional.dtd"/>
<public publicId="-//W3C//DTD XHTML 1.1//EN"
uri="dtd/xhtml11/xhtml11-flat.dtd"/>
</catalog>

150/360
JEP-282: jlink
 Assemble, optimize some modules and their
dependencies into a custom run-time image
– JEP-220: Modular run-time images
javac -d out module-info.java
javac -d out --module-path out
netptidejnewjavajlinkHelloWorld.java
jlink --module-path "%JAVA_HOME%jmods";out
--add-modules testJLinkModule
--output CustomJRE
cd CustomJRE/bib/
java --module testJLinkModule/net.ptidej.newjava.jlink.HelloWorld
https://www.baeldung.com/jlink

151/360
JEP-295: jaotc
 Ahead-of-time compilation
– Compile Java classes to native code
before launching the virtual machine
https://stackoverflow.com/questions/45298045/how-do-i-run-a-class-compiled-with-jaotc
javac Test.java
jaotc Test.class
jaotc --output libjava.base.so --module java.base
java -XX:AOTLibrary=./Test.so Test

154/360
JEP-286: Local-variable Type
Inference
final List<String> list1 = new ArrayList<>();
System.out.println(list1);
final var list2 = new ArrayList<String>();
System.out.println(list2);
vs.

156/360
JEP-304: GC Interface
 “Improve the source code isolation of
different garbage collectors by introducing a
clean garbage collector (GC) interface.”
https://medium.com/@unmeshvjoshi/writing-your-own-garbage-collector-for-jdk12-8c83e3d0309b
https://github.com/openjdk/jdk/blob/master/src/hotspot/share/gc/shared/collectedHeap.hpp#L90
class CollectedHeap : public CHeapObj<mtGC> {
virtual jint initialize() = 0;
virtual HeapWord* allocate_new_tlab(size_t min_size,
size_t requested_size,
size_t* actual_size) = 0;
virtual HeapWord* mem_allocate(size_t size,
bool* gc_overhead_limit_was_exceeded) = 0;
// ...

157/360
JEP-307: Parallel Full GC
 Improve G1 worst-case with full parallel GC
– Before Java 9: Parallel GC
– Since Java 9: G1
https://dev.java/evolution/

158/360
JEP-310: Application Class-Data
Sharing
 Improve startup and footprint
https://www.geeksforgeeks.org/class-data-sharing-in-java/
java -XX:+UnlockCommercialFeatures-XX:+UseAppCDS
-XX:DumpLoadedClassList=LoadedClasses.1st -jar AppCDS.jar
java -XX:+UnlockCommercialFeatures -Xshare:dump -XX:+UseAppCDS
-XX:SharedClassListFile=LoadedClasses.1st
-XX:SharedArchiveFile=CustomSharedArchive.jsa -cp AppCDS.jar
java -XX:UnlockCommercialFeatures -verbose -XShare:on
-XX:+UseAppCDS -XX:SharedArchiveFile=CUstomSharedArchive.jsa
-jar AppCDS.jar

159/360
JEP-312: Thread-local Handshakes
 Callback on threads without performing a
global VM safepoint
 Possible and cheap to stop individual
threads and not just all threads
-XX:ThreadLocalHandshakes=<true|false>

160/360
JEP-316: Heap Allocation on
Alternative Memory Devices
 Availability of cheap NVDIMM memory
– Non Volatile Dual In-line Memory Module
https://blog.workinghardinit.work/2019/07/18/a-quick-intro-to-nvdimm-n/
-XX:AllocateHeapAt=<path>

161/360
JEP-317: Experimental Java-based
JIT Compiler
 Efficient JIT compiler
for Java in Java
 As of 18/09/30
https://www.graalvm.org/
https://www.javacodegeeks.com/2018/10/java-graalvm-database-stream-performance.html
-XX:+UnlockExperimentalVMOptions
-XX:+UseJVMCICompiler

163/360
JEP-314: Additional Unicode
Language-Tag Extensions
 BCP 47 language tags
– Codes to identify languages
• en: English
• en-US: English, in United States
• km-Khmr-KH: Khmer, in Khmer script, in Cambodia
• km-fonipa: Khmer, transcribed in IPA
 Changes to many APIs
– java.text.DateFormat, java.util.Currency,
java.time.format.DateTimeFormatter, …
https://help.keyman.com/developer/current-version/reference/bcp-47

165/360
JEP-296: Consolidated JDK Forest
 Until Java 9
– Eight repos: root, corba, hotspot, jaxp, jaxws,
jdk, langtools, and nashorn
 Since Java 10
– One unified repository
$ROOT/jdk/src/java.base
...
$ROOT/langtools/src/java.compiler
...

166/360
JEP-296: Consolidated JDK Forest
 Until Java 9
– Eight repos: root, corba, hotspot, jaxp, jaxws,
jdk, langtools, and nashorn
 Since Java 10
– One unified repository
$ROOT/jdk/src/java.base
...
$ROOT/langtools/src/java.compiler
...
$ROOT/src/java.base
$ROOT/src/java.compiler
...

167/360
JEP-313: Native-Header Generation
Tool Removal
 javah features (and more) now in javac
javac HelloWorld.java
javah HelloWorld
javac -h jni -d bin HelloWorld.java
vs.

168/360
JEP-319: Root Certificates
 Default set of root Certification Authority
(CA) certificates
– Oracle Java SE Root CA becomes open source
– OpenJDK can use the same certificates

169/360
JEP-322: Time-based Release
Versioning
 New version scheme
final Version version = Runtime.version();
System.out.println(version);
System.out.print("Feature: ");
System.out.println(version.feature());
System.out.print("Interim: ");
System.out.println(version.interim());
System.out.print("Update: ");
System.out.println(version.update());
System.out.print("Patch: ");
System.out.println(version.patch());
System.out.print("Build: ");
System.out.println(version.build());
System.out.print("Optional: ");
System.out.println(version.optional());
System.out.print("Pre: ");
System.out.println(version.pre());

170/360
JEP-322: Time-based Release
Versioning
 New version scheme
final Version version = Runtime.version();
System.out.println(version);
System.out.print("Feature: ");
System.out.println(version.feature());
System.out.print("Interim: ");
System.out.println(version.interim());
System.out.print("Update: ");
System.out.println(version.update());
System.out.print("Patch: ");
System.out.println(version.patch());
System.out.print("Build: ");
System.out.println(version.build());
System.out.print("Optional: ");
System.out.println(version.optional());
System.out.print("Pre: ");
System.out.println(version.pre());
21.0.1+12-LTS-29
Feature: 21
Interim: 0
Update: 1
Patch: 0
Build: Optional[12]
Optional: Optional[LTS-29]
Pre: Optional.empty

173/360
JEP-181: Nest-based Access Control
 Before Java 11
– Bridge method, e.g.,
access$000(Example1)
 Since Java 11
– Direct access
– Access to nest mates’
private members
https://mkyong.com/java/java-11-nest-based-access-control/
private String name = "I'm Example1!";
public class A {
public void printName() {
}
}
public class B {
System.out.println(Example1.this.name);
}
public class B1 {
}
}
}
final Example1 e1 = new Example1();
final Example1.B b = e1.new B();
final Example1.B.B1 b1 = b.new B1();
b1.printName();
}
}

174/360
public class A {
}
}
public class B {
}
public class B1 {
}
}
}
System.out.println(A.class.getNestHost());
System.out.println(A.class.isNestmateOf(B.class));
for (final Class<?> clazz : Example2.B.class.getNestMembers()) {
System.out.println(clazz);
}
}
}

175/360
public class A {
}
}
public class B {
}
public class B1 {
}
}
}
System.out.println(A.class.getNestHost());
System.out.println(A.class.isNestmateOf(B.class));
for (final Class<?> clazz : Example2.B.class.getNestMembers()) {
System.out.println(clazz);
}
}
}
class net.ptidej.newjava.nest.Example2
true
class net.ptidej.newjava.nest.Example2
class net.ptidej.newjava.nest.Example2$A
class net.ptidej.newjava.nest.Example2$B
class net.ptidej.newjava.nest.Example2$B$B1

176/360
JEP-323: Local-variable Syntax for
Lambda Parameters
interface Comparator<T> {
int compare(final T a, final T b);
}
final Comparator<String> comparator1 = new Comparator<>() {
@Override
public int compare(final String a, final String b) {
return a.compareTo(b);
}
};
System.out.println(comparator1.compare("Hello", "World"));
final Comparator<String> comparator2 = (a, b) -> a.compareTo(b);
final Comparator<String> comparator3 = (String a, String b) -> a.compareTo(b);
final Comparator<String> comparator4 = (final var a, final var b) -> a.compareTo(b);
final Comparator<String> comparator5 = (@NonNull var a, @NonNull var b) -> a.compareTo(b);
}
}

177/360
JEP-323: Local-variable Syntax for
Lambda Parameters
interface Comparator<T> {
int compare(final T a, final T b);
}
final Comparator<String> comparator1 = new Comparator<>() {
@Override
public int compare(final String a, final String b) {
return a.compareTo(b);
}
};
final Comparator<String> comparator2 = (a, b) -> a.compareTo(b);
final Comparator<String> comparator3 = (String a, String b) -> a.compareTo(b);
final Comparator<String> comparator4 = (final var a, final var b) -> a.compareTo(b);
final Comparator<String> comparator5 = (@NonNull var a, @NonNull var b) -> a.compareTo(b);
}
}
Now posssible

179/360
JEP-309: Dynamic .class Constants
 Extend the class-file format with a new
constant-pool form
– CONSTANT_Dynamic
 Avoid initialising “expansive” values
– Also, no need to use volatile
https://www.javacodegeeks.com/2018/08/hands-on-java-constantdynamic.html

180/360
Problem: How to share some “expensive” data
among different threads?
Solution: Singleton design pattern
public class SomeExpensiveData {
public SomeExpensiveData() {
// Some very expensive (time, space) data to create
System.out.println("tSomeExpensiveData instance created");
}
}

181/360
public class MyCallable implements Callable<SomeExpensiveData> {
private static MyCallable UniqueInstance;
public static MyCallable getInstance() {
if (MyCallable.UniqueInstance == null) {
synchronized (MyCallable.class) {
MyCallable.UniqueInstance = new MyCallable();
}
}
}
return MyCallable.UniqueInstance;
}
private volatile SomeExpensiveData someExpensiveData;
private MyCallable() {
this.someExpensiveData = new SomeExpensiveData();
}
@Override
public SomeExpensiveData call() throws Exception {
return this.someExpensiveData;
}
}

182/360
}
}
}
}
}
@Override
}
}
Not a true constant
No caching, etc.

183/360
}
}
}
}
}
@Override
}
}
Not a true constant
No caching, etc.
Eager initialisation

184/360
 Dynamic constants
– Created once at run-time
– Can be shared among threads
– Can be cached, optimised, etc.
Problem: How to create dynamically a constant
Solution: CONSTANT_Dynamic

185/360
 Dynamic constants, javac vs. java
– Cannot be created from source code
• As of 24/03/24
– Can be created in the byte code
 Byte code generation, manipulation library
– Create, modify Java classes at run-time

186/360
final Unloaded<Callable> unloaded = new ByteBuddy().subclass(Callable.class)
.method(ElementMatchers.named("call")).intercept(FixedValue.value(
JavaConstant.Dynamic.ofInvocation(SomeExpensiveData.class.getConstructor()))).make();
final Constructor<? extends Callable> loaded =
unloaded.load(Example2.class.getClassLoader()).getLoaded().getConstructor();
final Callable<SomeExpensiveData> first = loaded.newInstance();
final Callable<SomeExpensiveData> second = loaded.newInstance();
System.out.println("tCallable instances created");
assertThat(first.call()).isEqualTo(second.call());

187/360
test_CONSTANT_Dynamic()
Callable instances created
SomeExpensiveData instance created

188/360
Lazy initialisation: two
instances created, but not
SomExpensiveData

189/360
Lazy initialisation: two
instances created, but not
SomExpensiveData
SomExpensiveData created
only once, with first call()

190/360
// (version 17 : 61.0, super bit)
public class net.bytebuddy.[...].Callable$ByteBuddy$7xbn1EIQ implements java.util.concurrent.Callable
public java.lang.Object call() throws java.lang.Exception;
0 ldc <Dynamic> 0 _ net.ptidej.newjava.constantdynamic.SomeExpensiveData [28]
2 areturn
public Callable$ByteBuddy$7xbn1EIQ();
0 aload_0 [this]
1 invokespecial java.lang.Object() [29]
4 return
Bootstrap methods:
0 : # 24 invokestatic java/lang/invoke/ConstantBootstraps.invoke:([...])Ljava/lang/Object;
Method arguments:
#17 net/ptidej/newjava/constantdynamic/SomeExpensiveData.<init>:()V

191/360
// (version 17 : 61.0, super bit)
public class net.bytebuddy.[...].Callable$ByteBuddy$7xbn1EIQ implements java.util.concurrent.Callable
public java.lang.Object call() throws java.lang.Exception;
0 ldc <Dynamic> 0 _ net.ptidej.newjava.constantdynamic.SomeExpensiveData [28]
2 areturn
public Callable$ByteBuddy$7xbn1EIQ();
0 aload_0 [this]
1 invokespecial java.lang.Object() [29]
4 return
Bootstrap methods:
0 : # 24 invokestatic java/lang/invoke/ConstantBootstraps.invoke:([...])Ljava/lang/Object;
Method arguments:
#17 net/ptidej/newjava/constantdynamic/SomeExpensiveData.<init>:()V
CONSTANT_Dynamic
with bootstrap method

192/360
JEP-331: Low-overhead Heap
Profiling
 Since Java 6
– No more JVM Profiler
Interface (JVMPI)
– No more JVM Debug
Interface (JVMDI)
– Replaced by JVM Tool
Interface (JVMTI)
 Sampling of Java heap
allocations
– All allocations
– Low-overhead
– Well-defined API
– Live, dead objects
https://docs.oracle.com/en/java/javase/11/docs/specs/jvmti.html

193/360
JEP-331: Low-overhead Heap
Profiling
https://docs.dynatrace.com/docs/platform-modules/applications-and-microservices/profiling-and-optimization/memory-profiling

194/360
JEP-333: Scalable Low-latency GC
 Z Garbage Collector
– GC pause no more than 10ms
– Handle megabyte to terabyte heaps
– No more than 15% throughput reduction wrt. G1
– Foundation for future features and optimisations
– (Only on 64bit operating systems)
-XX:+UnlockExperimentalVMOptions -XX:+UseZGC

196/360
JEP-320: Java EE and CORBA
Modules Removal
 Since Java 1.2
– OMG CORBA API
– ORB implementation
– CosNaming implementation
– idlj compiler
– Support for IDL and IIOP in rmic compiler
– No significant interest in CORBA anymore
 Since Java 6
– Full Web Services stack
– Now available from third parties
 Deprecated in Java 9

197/360
JEP-321: HTTP Client
 Problems with HttpURLConnection API
– Designed for (now dead) protocols (gopher…)
– Designed before HTTP/1.1
– Too abstract
– Hard to use
– Badly documented
– Blocking mode only
– Very hard maintenance

198/360
JEP-321: HTTP Client
 Three core classes
– HttpClient as a container for configuration
information common to multiple requests
– HttpRequest for requests sent by HttpClient
– HttpResponse for the result of an HttpRequest
https://www.baeldung.com/java-9-http-client

199/360
JEP-321:
final HttpRequest request = HttpRequest.newBuilder()
.uri(new URI("https://postman-echo.com/get"))
.version(HttpClient.Version.HTTP_2)
.timeout(Duration.ofSeconds(10))
.header("key1", "value1")
.GET()
.build();
final HttpClient client = HttpClient.newHttpClient();
final HttpResponse<String> response = client.send(request,
HttpResponse.BodyHandlers.ofString());
System.out.println(response.body());

200/360
JEP-321:
final HttpRequest request = HttpRequest.newBuilder()
.uri(new URI("https://postman-echo.com/get"))
.version(HttpClient.Version.HTTP_2)
.timeout(Duration.ofSeconds(10))
.GET()
.build();
final HttpClient client = HttpClient.newHttpClient();
final HttpResponse<String> response = client.send(request,
HttpResponse.BodyHandlers.ofString());
System.out.println(response.body());
{
"args": {},
"headers": {
"x-forwarded-proto": "https",
"x-forwarded-port": "443",
"host": "postman-echo.com",
"x-amzn-trace-id": "Root=1-660163f4-038cfd7075f93fad1e79f19e",
"key1": "value1",
"key2": "value2",
"user-agent": "Java-http-client/21.0.1"
},
"url": "https://postman-echo.com/get"
}

201/360
JEP-327: Unicode 10
 Major version of the Unicode Standard
 Support
– Character and String in java.lang
– NumericShaper in java.awt.font
– Bidi, BreakIterator, Normalizer in java.text

202/360
JEP-335: Nashorn Deprecation
 Since Java 8
– JEP-174
 ECMAScript changes rapidly
– Language
– APIs
 Maintenance challenges
– Deprecate Nashorn, its APIs, and jjs

204/360
JEP-328: Flight Recorder
 Monitoring tool
– Collects information about the events in a JVM
– An event
• Name
• Timestamp
• Other data
– Thread data, state of the heap, etc.
https://www.baeldung.com/java-flight-recorder-monitoring
-XX:+UnlockCommercialFeatures
-XX:+FlightRecorder
-XX:StartFlightRecording=duration=200s,filename=flight.jfr

205/360
JEP-328: Flight Recorder
https://www.baeldung.com/java-flight-recorder-monitoring

206/360
JEP-330: Single-file Source-code
Programs Launching
 Lower the (early) learning curve
– But no dependency management
java –cp some.jar HelloWorld.java

207/360
JEP-336: Pack200 Tools and API
Deprecation
 Since Java 5
– Compression scheme for JAR files
– To accommodate 56k modems
 Since Java 9 (and JEP-220)
– Modules
– Compression
– No more applets
– Maintenance challenges
– Modularisation challenges

210/360
 Nothing to mention?

212/360
JEP-344: Abortable Mixed
Collections
 Ability for G1 to abort its collection pauses
 G1 predicts the number of regions to collect
and proceeds only with abortable ones
 Lower pause latency and higher probability
to achieve pause-time target
https://blogs.oracle.com/javamagazine/post/understanding-the-jdks-new-superfast-garbage-collectors
-XX:G1MixedGCCountTarget=<number of mixed garbage collections>

213/360
JEP-346: Unused Committed
Memory Prompt Return
 G1 automatically returns heap memory to
the operating system when idle
-XX:G1PeriodicGCInterval=<true|false>
-XX:G1PeriodicGCInvokesConcurrent=<true|false>
-XX:G1PeriodicGCSystemLoadThreshold=<average 1-minute system load>

215/360
JEP-334: JVM Constants API
 API to describes some class-file and run-
time elements (e.g., constants)
https://iampravo.medium.com/java-12-features-and-highlights-81938474cd31
final ClassDesc example1ClassDesc = ClassDesc.of("[...].constantsapi", "Example1");
final MethodTypeDesc mainMethodTypeDesc = MethodTypeDesc.of(example1ClassDesc);
final MethodHandleDesc mainMethodHandleDesc = MethodHandleDesc.ofMethod(
DirectMethodHandleDesc.Kind.STATIC, example1ClassDesc, "main", mainMethodTypeDesc);
System.out.println("Class descriptor: " + example1ClassDesc);
System.out.println("Method type descriptor: " + mainMethodTypeDesc);
System.out.println("Method handle descriptor: " + mainMethodHandleDesc);
}
}

216/360
JEP-334: JVM Constants API
 API to describes some class-file and run-
time elements (e.g., constants)
https://iampravo.medium.com/java-12-features-and-highlights-81938474cd31
final ClassDesc example1ClassDesc = ClassDesc.of("[...].constantsapi", "Example1");
final MethodTypeDesc mainMethodTypeDesc = MethodTypeDesc.of(example1ClassDesc);
final MethodHandleDesc mainMethodHandleDesc = MethodHandleDesc.ofMethod(
DirectMethodHandleDesc.Kind.STATIC, example1ClassDesc, "main", mainMethodTypeDesc);
System.out.println("Class descriptor: " + example1ClassDesc);
System.out.println("Method type descriptor: " + mainMethodTypeDesc);
System.out.println("Method handle descriptor: " + mainMethodHandleDesc);
}
}
Class descriptor: ClassDesc[Example1]
Method type descriptor: MethodTypeDesc[()Example1]
Method handle descriptor: MethodHandleDesc[STATIC/Example1::main()Example1]

218/360
JEP-230: Microbenchmark Suite
 Java Microbenchmark Harness (JMH)
– An annotation-based DSL
• @State, @Fork, @Warmup, @Measurement, @Benchmark…
 Microbenchmarks suite integrated into
OpenJDK source code
https://cl4es.github.io/2018/11/16/JEP-230-Microbenchmarks-Suite.html
make build-microbenchmark

219/360
 Java Microbenchmark Harness (JMH)
– An annotation-based DSL
• @State, @Fork, @Warmup, @Measurement, @Benchmark…
 Microbenchmarks suite integrated into
OpenJDK source code
https://cl4es.github.io/2018/11/16/JEP-230-Microbenchmarks-Suite.html
make build-microbenchmark
build/$PROFILE/images/test/micro/benchmarks.jar

220/360
 Run one java.util.UUIDBench benchmark
– https://github.com/openjdk/jdk/blob/master/test/mi
cro/org/openjdk/bench/java/util/UUIDBench.java
https://cl4es.github.io/2021/01/04/Investigating-MD5-Overheads.html
make test TEST=micro:UUIDBench.fromType3Bytes

221/360
 Run one java.util.UUIDBench benchmark
– https://github.com/openjdk/jdk/blob/master/test/mi
cro/org/openjdk/bench/java/util/UUIDBench.java
https://cl4es.github.io/2021/01/04/Investigating-MD5-Overheads.html
make test TEST=micro:UUIDBench.fromType3Bytes
Benchmark Score Error Units
fromType3Bytes 1.460 ± 0.089 ops/us

222/360
 Benchmarking the
JVM is difficult
– Just-in-time compiler
– Dead code elimination
– Loop unrolling
– Method inlining
– …
– Warmup iterations
– Iteration durations
– …
https://www.oracle.com/technical-resources/articles/java/architect-benchmarking.html

223/360
Java 13
2019/09/17
2019/09/17
2019/09/17
2019/09/17

225/360

227/360
JEP-351: Unused Memory
Uncommit
 ZGC automatically returns heap memory to
the operating system when idle
– Cf. JEP-346
-XX:ZUncommitDelay=<seconds>

229/360
JEP-353: Legacy Socket API
Reimplementation
 Reimplementations
– java.net.Socket
– java.net.ServerSocket
 Simpler, modern
 Easier to maintain, debug
 Ready for user-mode threads
– Fibers, Project Loom

231/360

234/360
-XX:+ShowCodeDetailsInExceptionMessages
JEP-358: Helpful
NullPointerExceptions
 Describe precisely which variable was null
class Employee {
String getName() {
// return "Bob";
return null;
}
}
final Employee e = new Employee();
e.getName().toString();
}
}

235/360
JEP-358: Helpful
class Employee {
String getName() {
// return "Bob";
return null;
}
}
}
}
Exception in thread "main" java.lang.NullPointerException
at net.ptidej.newjava.helpfulnullpointerexceptions.Example1.main(Example1.java:13)

236/360
JEP-358: Helpful
class Employee {
String getName() {
// return "Bob";
return null;
}
}
}
}
Exception in thread "main" java.lang.NullPointerException
Exception in thread "main" java.lang.NullPointerException: Cannot invoke
"String.toString()" because the return value of "[...].Employee.getName()" is null

237/360
JEP-361: switch Expressions
https://medium.com/@imagarg/switch-expression-jep-361-3b5649ec36c9
private static int getDayLength(final Day day) {
int numberOfCharacters = 0;
switch (day) {
case MONDAY:
case FRIDAY:
case SUNDAY:
numberOfCharacters = 6;
break;
case TUESDAY:
break;
case THURSDAY:
case SATURDAY:
break;
case WEDNESDAY:
break;
default:
throw new IllegalArgumentException();
}
return numberOfCharacters;
}
private static int getDayLength(final Day day) {
int result = switch (day) {
case MONDAY, FRIDAY, SUNDAY -> 6;
case TUESDAY -> 7;
case THURSDAY, SATURDAY -> 8;
case WEDNESDAY -> 9;
default ->
throw new IllegalArgumentException();
};
return result;
}
enum Day {
MONDAY, TUESDAY,
WEDNESDAY,
THURSDAY, FRIDAY,
SATURDAY, SUNDAY;
}

239/360
JEP-345: NUMA-Aware Memory
Allocation
 NUMA-aware memory
allocation to increase
G1 performance
– Non-uniform memory
access
– Multi-socket computers
• E.g., HP Z820
-XX:UseParallelGC=<true|false>

240/360
JEP-345: NUMA-Aware Memory
Allocation
 NUMA-aware memory
allocation to increase
G1 performance
– Non-uniform memory
access
– Multi-socket computers
• E.g., HP Z820
-XX:UseParallelGC=<true|false>
Two CPUs, with
their own DIMMs

Evolution and Examples of Java Features, from Java 1.7 to Java 22

Evolution and Examples of Java Features, from Java 1.7 to Java 22

Recommended

Recommended

More Related Content

Similar to Evolution and Examples of Java Features, from Java 1.7 to Java 22

Similar to Evolution and Examples of Java Features, from Java 1.7 to Java 22 (20)

More from Yann-Gaël Guéhéneuc

More from Yann-Gaël Guéhéneuc (20)

Recently uploaded

Recently uploaded (20)

Evolution and Examples of Java Features, from Java 1.7 to Java 22
