The Deploying OpenStack with Chef section of the OpenStack Workshop from Velocity 2011

1. Deploying OpenStack with Opscode Chef
matt@opscode.com
www.opscode.com

2. Who am I?
• Matt Ray
• Senior Technical Evangelist
• Opscode, Inc.
• Twitter/GitHub/Launchpad/IRC: mattray

3. Deploying OpenStack is
not simple.

4. Chef makes it easier.

5. Infrastructure as Code

6. Enable the reconstruction
of the business from
nothing but a source code
repository, an application
data backup, and bare
metal resources.

7. Configuration
Management

8. System Integration
http://www.flickr.com/photos/opalsson/3773629074/

10. The Chef Framework
• Reasonability
• Flexibility
• Library & Primitives
• TIMTOWTDI

11. The Chef Tool(s)
• ohai
• chef-client
• knife
• shef

12. The Chef API
• Client/Server
• RESTful API w/ JSON
• Search Service
• Derivative Services

13. The Chef Community
• Apache License, Version 2.0
• 360+ Individual contributors
• 70+ Corporate contributors
• Dell, Rackspace,VMware, RightScale,
Heroku, and many more
• 240+ cookbooks
• http://community.opscode.com

14. openstack-cookbooks
Resources

15. github.com/mattray/openstack-cookbooks
• Chef repository
• cookbooks
• roles
• data bags
• stable branches
• issues

16. Chef Nodes
• Each system you manage is called a node.
• The chef-client runs on nodes.
• The ohai discovery agent runs on nodes.
• Nodes have a run list.
• Searchable

17. Chef Resources
package "haproxy" do
action :install
end
• Have a type.
•
template "/etc/haproxy/haproxy.cfg" do
Have a name. source "haproxy.cfg.erb"
• Have parameters.
owner "root"
group "root"
• Take action to put the resource mode 0644
notifies :restart, "service[haproxy]"
in the declared state. end
• Can send notifications to other service "haproxy" do
resources. supports :restart => true
action [:enable, :start]
• Take action through Providers end

18. Chef Recipes
extra_packages = case node[:platform]
when "ubuntu","debian"
%w{
ruby1.8
ruby1.8-dev
• Ordered list of Resources rdoc1.8
ri1.8
• Idempotent execution }
libopenssl-ruby
• Ruby
end
extra_packages.each do |pkg|
package pkg do
action :install
end
end

19. Chef Cookbooks
• Cookbooks are packages for Recipes
• Recipes
• Assets (files/templates)
• Attributes
• Metadata
• Distributable and managed as Source
• community.opscode.com

20. OpenStack Cookbooks
• Included
• glance
• nova
• swift
• Installed
• apache2
• apt
• mysql
• openssl
• rabbitmq

21. Chef Roles
• Roles describe the node.
• Roles have run lists.
• Roles have attributes.
• Roles may contain other roles.
• Searchable.
• Webserver, database, Hadoop-worker, etc.

22. OpenStack Roles
• nova-single-machine
• nova-db
• nova-rabbitmq-server
• glance-single-machine
• nova-multi-controller
• nova-multi-compute

23. Chef Data Bags
• Data bags store arbitrary data
• JSON
• Searchable

24. OpenStack Data Bags
knife data bag create openstack
knife data bag from file openstack defaults.json
knife data bag from file openstack glance.json
knife data bag from file openstack images.json
knife data bag show openstack images
id: images
images:
http://uec-images.ubuntu.com/lucid/current/ubuntu-10.04-
server-uec-amd64.tar.gz:
arch: x86_64
distro: Ubuntu
image: lucid-server-uec-amd64.img
kernel: lucid-server-uec-amd64-vmlinuz-virtual
version: 10.04

26. Deploying OpenStack
• Scaling changes how we deploy!
• Single machine works
• Controller + N Computes work(ed)
• Nova and/or Swift installations
• Configurations will be supported, shared &
documented

27. Spiceweasel
• yaml/json for describing infrastructure
• generates knife commands
• shareable "best practices"
• infrastructure.yml included
• bit.ly/spcwsl

28. Testing OpenStack
• bare-metal to OpenStack
• ~15 minutes
• pxe_dust cookbook
• 2 networks
• admin
• public

29. knife openstack

30. knife openstack
$ gem install knife-openstack
$ knife openstack
** OPENSTACK COMMANDS **
knife openstack server list (options)
knife openstack flavor list (options)
knife openstack server create (options)
knife openstack server delete SERVER [SERVER] (options)
knife openstack image list (options)

31. knife.rb
knife[:openstack_access_key_id] = "MeMpLexdnjmXeXGMx:admin"
knife[:openstack_secret_access_key] = "nFjXAKl5G6VaXE3bVuwi"
knife[:openstack_api_endpoint] =
"http://192.168.11.9:8773/services/Cloud"

32. knife openstack server create -S mykey -x ubuntu
-I ami-4b0ff834 -f m1.tiny -r 'role[webserver]'

33. How did we get here?
git clone git://github.com/mattray/openstack-cookbooks.git

34. Origins
• Forked from Anso Labs
• Bootstrapped originally by Opscode
• Chef Solo/Vagrant installs for Developers
• http://github.com/ansolabs/openstack-cookbooks

35. Crowbar
• OpenStack installer from Dell
• Dell is releasing this under the Apache 2
license
• Extension of the Chef server
• Developed by Dell, Rackspace & Opscode
• http://github.com/dellcloudedge

36. What's Next?
http://www.flickr.com/photos/felixmorgner/4347750467/

37. Nova Roadmap
• Improve Glance integration
• Network Types
• Flat, FlatDHCP, VLANs
• Multiple Hypervisors
• Xen, LXC, Hyper-V
• Databases
• PostgreSQL, Drizzle

38. Swift Roadmap
• Multiple Implementations Available
• Dell
• http://github.com/dellcloudedge/openstack-swift
• Voxel
• http://www.voxel.net/blog/2011/05/openstack-swift-chef-
and-spiceweasel-part-1-0
• http://github.com/voxeldotnet/openstack-swift-chef

39. Dashboard

40. OpenStack Roadmap
• Diablo release
• RHEL 6 & Fedora
• Windows

41. Get Involved!
• http://github.com/mattray/openstack-
cookbooks/tree/cactus
• http://wiki.opscode.com/display/chef/
Deploying+OpenStack+with+Chef
• irc.freenode.net #chef #openstack
• Twitter/GitHub/Launchpad/IRC:mattray
• matt@openstack.org/matt@opscode.com

42. Questions?
http://www.flickr.com/photos/mrchippy/443960682/

43. Thanks!
http://www.opscode.com
